Source field determines which module provides the digital input.Name field determines the label of the event.Event Table tab - set according to the image, where:.Measurement tab - External Start/Stop enabled and set to Start Only.HW with digital input or Virtual Digital Input Output Loop module configured to Instrument.The digital input can be triggered by pressing the start button when it is provided by HW, or by pressing the corresponding Digital Output in the Device monitor when provided by the Virtual Digital Input Output Loop module. With proper settings, triggering the digital input is recorded as an event (vertical line labeled with name and RT) in the Acquisition and Chromatogram windows.
Colibrick A/D converter) or the Virtual Digital Input Output Loop module and Event Table tab from the Method Setup dialog. Mark in a chromatogram can be created utilizing any HW with digital input (e.g.
